Leadshine CABLEH-BM10M0 encoder cable for CS-M/CS-D series closed loop stepper systems.
10.0 meters (32.8 foots) long.

Leadshine CS-M22323 NEMA 23 closed loop stepper motor.
Holding torque 2.3 Nm.
Current 5.00 A.
96 mm (3.78 inch) long.
8 mm (0.315 inch) shaft size.
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder.

Leadshine CABLE-BMAH5M0-124-TS absolute encoder cable for servo systems.
CABLE-BMAH5M0-124-TS is for ELM1/2 series motors and EL6/EL7/EL8 series drives.
Leadshine CABLE-BMAH5M0-124-TS is for connect an absolute servo motor encoder.
5.0 meters (16.4 foots) long.

Leadshine CABLE-RZH5M0-114-TS power cable for servo systems.
CABLE-RZH5M0-114-TS is for ELM1/2 series motors without brake and EL6/EL7/EL8 series drivers.
5.0 meters (16.4 foots) long.

Sterownik silnika serwo Leadshine EL7-RS750P.
Moc znamionowa 750 W.
Napięcie wejściowe 230 VAC.
Prąd znamionowy (szczytowy) 5.5 (16.9) A.
EL7-RS750P obsługuje tryby sterowania: Modbus RTU, Pulse+Direction lub analogowy.
Konfigurowalne wejścia/wyjścia: 8 DI, 5 DO, 2 AI and 1 AO.

Silnik serwo AC Leadshine ELM1H-0750MA80F.
Model ELM1H-0750MA80F posiada 23-bitowy magnetyczny enkoder.
Rozmiar ramy 80 mm.
Moc znamionowa 750 W.
Napięcie znamionowe 230 VAC.
Moment znamionowy (szczytowy) 2.39 (7.17) Nm.
Prędkość znamionowa (szczytowa) 3000 (5000) obr./min.
Prąd znamionowy (szczytowy) 4.1 (13.4) A.
Masa 2.12 kg.

Leadshine CABLE-RZSH5M0-114-TS power cable for servo systems.
CABLE-RZSH5M0-114-TS is for ELM1/2 series motors with Brake and EL6/EL7/EL8 series drivers.
5.0 meters (16.4 foots) long.

Sterownik silnika serwo Leadshine EL7-RS400P.
Moc znamionowa 400 W
Napięcie wejściowe 230 VAC.
Prąd znamionowy (szczytowy) 3,5 A (9,5 A).
Model EL7-RS400P obsługuje tryby sterowania: Modbus RTU, Pulse+Direction lub analogowy.
Konfigurowalne wejścia/wyjścia: 8 DI, 5 DO, 2 AI i 1 AO

Silnik serwo AC Leadshine ELM1H-0400MA60E z hamulcem.
Model ELM1H-0400MA60E posiada 23-bitowy magnetyczny enkoder.
Rozmiar ramy 60 mm.
Moc znamionowa 400 W.
Napięcie znamionowe 230 VAC.
Moment znamionowy (szczytowy) 1.27 (3.81) Nm.
Prędkość znamionowa (szczytowa) 3000 (5000) obr./min.
Prąd znamionowy (szczytowy) 2.1 (6.5) A.
Masa 1.55 kg.

Leadshine CS-D508 sterownik silnika krokowego z pętlą sprzężenia zwrotnego.
Napięcie wejściowe 20 - 50 VDC.
Prąd wyjściowy 0,50 - 8,00 A.
Sterownik CS-D508 obsługuje tryby sterowania Krok+Kierunek (PUL/DIR) lub Zgodnie/Przeciwnie do ruchu wskazówek zegara (CW/CCW). Zamknięty sterownik silnika krokowego Leadshine CS-D508 jest łatwy w konfiguracji za pomocą przełączników DIP.

Falownik Kinco FV20-2S-0022G.
Moc znamionowa 2.2 kW.
Napięcie wejściowe 230 VAC.
Prąd znamionowy (szczytowy) 10 (18) A.
Częstotliwość wyjściowa 0 Hz...300 Hz.
Komunikacja szeregowa: Modbus RTU.
Sterowanie momentem obrotowym: Wektorowe, Skalarne.
Konfigurowalne wejścia/wyjścia: 6 DI, 3 DO, 2 AI oraz 2 AO.

Leadshine CABLE-PC-1 cable for tuning stepper and servo systems.
RS232.
1.2 meters (3.9 foots) long.

Leadshine CABLE-TYPEC2M0 cable for tuning servo systems.
CABLE-TYPEC2M0 cable for communication cable to EL7 and EL8 series servo drivers.
2 meters (6.6 foots) long.

Leadshine CABLE-PC cable for tuning stepper systems.
CABLE-PC cable for communication cable to DM/EM series stepper drivers.
RS232.
1.2 meters (3.9 foots) long.

Leadshine CS-M22313 NEMA 23 closed loop stepper motor.
Holding torque 1.3 Nm.
Current 4.00 A.
75 mm (2.95 inch) long.
8 mm (0.315 inch) shaft size.
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder.

Hiwin D2T-0423-S-B4 servo driver.
Rated power 400 W.
Input voltage 230 VAC.
Current rated (peak) 2.5 (3.7) A
D2T-0423-S-B4 takes Pulse+Direction control modes.
User-configurable I/O: 9 DI, 4 DO and 1 AI.

Hiwin HVPS06AA10MB power cable for servo systems.
HVPS06AA10MB is for FR series motors with Brake and D2T series drivers.
10.0 meters (32.8 foots) long.

Hiwin HVPS06AA05MB power cable for servo systems.
HVPS06AA05MB is for FR series motors with Brake and D2T series drivers.
5.0 meters (16.4 foots) long.

Hiwin HVE17IAB10MB incremental encoder cable for servo systems.
HVE17IAB10MB is for FR series motors and D2T series drivers.
Hiwin HVE17IAB10MB is for connect an incremental servo motor encoder.
10.0 meters (32.8 foots) long.

Hiwin HVE13IAB05MB incremental encoder cable for servo systems.
HVE13IAB05MB is for FR series motors and D2T series drivers.
Hiwin HVE13IAB05MB is for connect an incremental servo motor encoder.
5.0 meters (16.4 foots) long.

Hiwin FR-LS-40-2-B-6-06-D AC servo motor with brake.
The FR-LS-40-2-B-6-06-D has 17bit encoder.
Frame size 60 mm.
Rated power 400 W.
Rated voltage 230 VAC.
Torque rated (peak) 1.27 (3.81) Nm.
Speed rated (peak) 3000 (4500) rpm.
Current rated (peak) 2.5 (7.5) A.
Weight 1.86 kg.

Hiwin FR-LS-40-2-B-6-06-A AC servo motor with brake.
The FR-LS-40-2-B-6-06-A has 17bit encoder.
Frame size 60 mm.
Rated power 400 W.
Rated voltage 230 VAC.
Torque rated (peak) 1.27 (3.81) Nm.
Speed rated (peak) 3000 (4500) rpm.
Current rated (peak) 2.5 (7.5) A.
Weight 1.86 kg.

Hiwin ED2S-V0-003-1-C-00 servo driver.
Rated power 500 W.
Input voltage 230 VAC.
Current rated (peak) 3.0 (12.0) A
ED2S-V0-003-1-C-00 takes Pulse+Direction control modes.
User-configurable I/O: 9 DI, 5 DO, 1 AI and 2 AO.

Tr12x3 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr50x8 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr40x7 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr36x6 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr30x6 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr24x5 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr20x4 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr16x4 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr14x3 FEU Right hand bronze trapezoidal flange nut.
Manufactured in accordance with ISO DIN 103, tolerance 7H.
We can produce special nuts according to customers drawings in different materials.

Tr12x3 Precision rolled screw trapezoidal thread in steel C15-1.1141.
Manufactured in accordance with ISO DIN 103, 7e tolerance (0,2/300mm).
We can produce screw according to customers drawings.

Tr14x3 Precision rolled screw trapezoidal thread in steel C15-1.1141.
Manufactured in accordance with ISO DIN 103, 7e tolerance (0,2/300mm).
We can produce screw according to customers drawings.

Tr14x4 Precision rolled screw trapezoidal thread in steel C15-1.1141.
Manufactured in accordance with ISO DIN 103, 7e tolerance (0,2/300mm).
We can produce screw according to customers drawings.

Tr16x4 Precision rolled screw trapezoidal thread in steel C15-1.1141.
Manufactured in accordance with ISO DIN 103, 7e tolerance (0,2/300mm).
We can produce screw according to customers drawings.
